74HC161 IC - (SMD Package) - 4-Bit Presettable Synchronous Binary Counter IC (74161)

The 74HC161 is a synchronous presettable binary counter with an internal look-head carry. Synchronous operation is provided by having all flip-flops clocked simultaneously on the positivegoing edge of the clock (CP). The outputs (Q0 to Q3) of the counters may be preset HIGH or LOW. A LOW at the parallel enable input (PE) disables the counting action and causes the data at the data inputs (D0 to D3) to be loaded into the counter on the positive-going edge of the clock. Preset takes place regardless of the levels at count enable inputs (CEP and CET). A LOW at the master reset input (MR) sets Q0 to Q3 LOW regardless of the levels at input pins CP, PE, CET and CEP (thus providing an asynchronous clear function). The look-ahead carry simplifies serial cascading of the counters. Both CEP and CET must be HIGH to count. The CET input is fed forward to enable the terminal count output (TC). The TC output thus enabled will produce a HIGH output pulse of a duration approximately equal to a HIGH output of Q0. This pulse can be used to enable the next cascaded stage. The maximum clock frequency for the cascaded counters is determined by the CP

to TC propagation delay and CEP to CP set-up time.

Features :-

• Wide supply voltage range from 2.0 V to 6.0 V
• CMOS low power dissipation
• High noise immunity
• Latch-up performance exceeds 100 mA per JESD 78 Class II Level B
• Complies with JEDEC standards:

JESD8C (2.7 V to 3.6 V)

JESD7A (2.0 V to 6.0 V)

• CMOS input levels
• Synchronous counting and loading
• 2 count enable inputs for n-bit cascading
• Asynchronous reset
• Positive-edge triggered clock
• ESD protection:

HBM JESD22-A114F exceeds 2000 V

MM JESD22-A115-A exceeds 200 V

• Specified from -40 °C to +85 °C and -40 °C to +125 °C

Specifications :-

Parameter	Min	Max	Unit
Supply voltage	-0.5	+7.0	V
Input clamp current	-	+20	mA
Output clamp current	-	+20	mA
output current	-	+25	mA
supply current	-	50	mA
ground current	-50	-	mA
storage temperature	-65	+150	°C
total power dissipation	-	500	mW

Package Includes :-

1 X 74HC161 Presettable Synchronous 4-bit Binary Counter IC (74161 IC) DIP-16 Package
