- BY299 Fast / Ultrafast Power Diode
Click Image to Preview
BY299 Fast / Ultrafast Power Diode
Brand: Generic | SKU: 1688064
₹ 8.00
₹ 15.00
Enter your pincode to check delivery options
Offer & Other Details
- Payment Offer: 2% Instant Discount on UPI and bank Transfer Payments.
- Partial COD: Pay 25% Advance now and Balance on Delivery (COD).
- Sales Assistance: Contact us +91 8903831010 for personalized advice.
Description
The BY299 is the Fast Recovery Rectifier Diodes. The typical applications of BY299 are the rectification of medium frequencies, snubber or Bootstrap diodes Commercial grade.
Features:-
• High current capability
• High surge current capability
• High reliability
• Low reverse current
• Low forward voltage drop
• Fast switching for high efficiency
Mechanical Characteristics:-
• Case : DO-201AD Molded plastic
• Epoxy : UL94V-O rate flame retardant
• Lead : Axial lead solderable per MIL-STD-202, Method 208 guaranteed
• Polarity : Color band denotes cathode end
• Mounting position : Any
• Weight : 1.16 grams
Specification:-
| Symbol | Parameter | Value | Units |
| VRRM | Peak Repetitive Reverse Voltage | 800 | V |
| VRMS | Maximum RMS Voltage | 560 | V |
| VDC | Maximum DC Blocking Voltage | 800 | V |
| VF | Maximum Peak Forward Voltage at IF = 2.0 Amps | 1.3 | V |
| CJ | Typical Junction Capacitance | 28 | pf |
| IFSM | Non-Repetitive Peak Forward Surge Current | 70 | A |
| TJ | Operating Junction Temperature Range | - 50 to + 125 | °C |
| Tstg | Storage Temperature Range | - 50 to + 125 | °C |
| IF(AV) | Maximum Average Forward Current 0.375"(9.5mm) Lead Length Ta = 50 °C | 2 | A |
Related Document:-
